PNEUMATIC SWING CLAMPS WITH ADJUSTABLE SWING DIRECTION – 89R SERIES
DESTACO - Workholding Equipment & Automation Tooling Solutions
Clamping
Pneumatic Clamping
Pneumatic Swing Clamps
Pneumatic Swing Clamps-89R
89R40-025-2 - PNEUMATIC SWING CLAMP
89R40-025-2 - PNEUMATIC SWING CLAMP
Email product details
Visit Product Series:
Pneumatic Swing Clamps-89R
Request Quote
Configure with accessories
Technical Details
CAD / Configure
Accessories
Resources
FAQs
Articles
Technical Details
Unit View
Imperial
Metric
Dimensions / Applications
Length (in)
7.67
Weight (lb)
2.4
Product Application
CLAMPING
Technical Details
Air Consumption (per double stroke at 7 psi) (in³)
0.022
Clamping Force @ 5Bar[72Psi] (lbf.)
85.0
Cylinder Bore (in)
1.57
Stroke (in)
1.83
Stroke during rotation (in)
0.85
Air Port size
G-1/8
Mount
Block style
Supplied?
No
Swing Direction
LH, RH, Straight
Product Information
Accessories
8EA-109-1|CABL-010|CABL-013|89R40-00|8JG-218-1|8MA-087-1|8MA-095-1|8MW-021-1|8MA-064-1
Brand
DESTACO
Product Type
Pneumatic Swing Clamp
Sensor Ready
Yes
Spindle Included?
No
