RIGHT ANGLE, ROTARY INDEX DRIVES WITH UNIVERSAL MOUNTING – RA SERIES

Default Image

512RA3H32-180_MSC_0.33 - Right Angle Index Drive

Visit Product Series:

Mechanical Rotary Indexers-RA

Unit View

Dimensions / Applications

Technical Details

  • Center Distance (in)2.375
  • Height To Mounting Surface (in)11.43
  • Internal Inertia (lb-in²)44
  • Maximum Inertia Load at 60 indexes per minute (lb-in² x 1000)1.739
  • Maximum Torque (in-lb)3231
  • Mounting Surface Diameter (in)3.38
  • Output Overturning Moment Capacity (in-lb)6951
  • Output Radial Capacity (lb)1986
  • Output Shaft Diameter (in)1.625
  • Output Thrust/Axial Capacity (lb)2277

Product Information

  • Base Model512RA3H32-180_MSC_0.33
  • BrandCamco
  • Product TypeRight Angle Index Drive
  • Spindle Included?No
