Manual Clamping

Hold Down Clamps

DESTACO’s 227 Series horizontal hold down clamps feature a low profile design, availability in stainless steel models, and large handle clearance in the open position.

LOW-PROFILE, MANUAL HORIZONTAL HOLD DOWN CLAMPS – 227 SERIES

DESTACO’s 227 Series horizontal hold down clamps feature a low profile design, availability in stainless steel models, and large handle clearance in the open position. These clamps are used in assembly, fixture checking, woodworking, and closures.

Colored handles available - click here to learn more!

Features

  • Holds up to 1,000 lbs (4,450 N) capacity
  • Heavy Duty horizontal clamps with high strength and long life.
  • Low height design
  • Many equipped with DESTACO Toggle Lock Plus®, an innovative safety feature that adds a secondary lock to the clamp to help ensure that the over-center locking condition is maintained and protected against unintentional opening.
  • Low silhouette hold down clamp features a handle that can be operated from either side or from behind
  • Unique standard design gives greater hand clearance between the bar and handle, providing optimal overhead clearance.

Markets

Applications

  • Fixturing and Testing
Product
Short Description
Product Type
Standard Material
Base Mounting Style
Handle Color
Clamp Arm Length (in)
Clamp Bar Opening (+10°) (degrees)
Clamp Arm Style
Accomodates Workpiece Variation
Weight (lbs)
Maximum Holding Capacity (lbf)
Handle
Service Environment
Handle Opening (+10°)
Height Under Clamp Arm (in)
227-U
Horizontal Hold-Down Toggle Locking Clamp, Flanged Base, U-BarHorizontal Hold-Down Toggle ClampSteelFlangeRed2.6591U-BarNo0.7500HorizontalNormal561.25
227-U-B
Horizontal Hold-Down Toggle Locking Clamp, Straight Base, U-barHorizontal Hold-Down Toggle ClampSteelFlangeBlue2.6591U-BarNo0.68500HorizontalNormal561.25
227-UB-L
Horizontal Hold-Down Toggle Locking Clamp, Straight Base, Open BarHorizontal Hold-Down Toggle ClampSteelStraightRed2.3991Open U-BarNo0.7500HorizontalNormal561.45
227-U-L
Horizontal Hold-Down Toggle Locking Clamp, Flanged Base, Open BarHorizontal Hold-Down Toggle ClampSteelFlangeRed2.3991Open U-BarNo0.7500HorizontalNormal561.25
227-USS
Horizontal Hold-Down Toggle Locking Clamp, Stainless Steel Version of 227-UHorizontal Hold-Down Toggle ClampStainless SteelFlangeRed2.6691U-BarNo0.68600HorizontalNormal561.28
227-UB
Horizontal Hold-Down Toggle Locking Clamp, Straight Base, U-barHorizontal Hold-Down Toggle ClampSteelStraightRed2.6591U-BarNo0.7500HorizontalNormal561.45
227-U-G
Horizontal Hold-Down Toggle Locking Clamp, a 227-U with Green HandleHorizontal Hold-Down Toggle ClampSteelFlangeGreen2.6591U-BarNo0.68500HorizontalNormal561.25
227-U-Y
Horizontal Hold-Down Toggle Locking Clamp, a 227-U with Yellow HandleHorizontal Hold-Down Toggle ClampSteelFlangeYellow2.6591U-BarNo0.68500HorizontalNormal561.25
227-U-K
Horizontal Hold-Down Toggle Locking Clamp, a 227-U with Black HandleHorizontal Hold-Down Toggle ClampSteelFlangeBlack2.6591U-BarNo0.68500HorizontalNormal561.25
